121-1 series High-Density Edge Connector with Mounting Ears

Technical data:
Insulator: High temperature thermoplastic, UL 94V-0
Color Insulator: Black
Burning properties: Self extinguishing
                                      to UL94V0
Contact: Copper alloy
Contact surface: Mating area gold over nickel
                                Solder area tin over nickel
Operating temperature: -55℃ to + 105℃
Electrical data:
Current rating: 1A
Electrical rating: min. 500V
Insulation resistance: min. 1000 MOhm
